SGPC Itx Mini Case K77 Lite && 9225-1pick LED Fan
SGPC K77 lite Compact ITX Case.With 3mm Tempered Glass Side Panel. Compatible with ITX motherboard and SFX or ATX power supply.11.6L mini chassis that can support up to 6 chassis fans
【Size】: Ultra-Compact Mini ITX Case measuring 11.4 x 6.3 x 9.84 inches and 11.6L. Includes two optional handles (one plastic, one leather) that can be installed for easy mobility and versatile setup.
【Material Quality】: The case is constructed from 1-1.7mm thick steel, complemented by a 3mm tempered glass side panel for durability and aesthetic appeal.
【Front I/O】: Features dual USB 3.0 and Type-C ports via a single 19-pin motherboard connector, delivering high-speed data transfer of up to 5GB/s.
【Power Compatibility】: The K77LITE is compatible with both SFX (125 x 100 x 64 mm / 4.92" x 3.94" x 2.55") and ATX (150 x 140 x 86 mm / 5.9" x 5.51" x 3.39") power supplies, and supports air coolers up to 135mm in height. Note that it does not support SFX-L power supplies. When paired with an SFX power supply, it can accommodate a 120mm AIO liquid cooler with a CPU block height under 50mm, in addition to air cooling options. However, when using an ATX power supply, liquid cooling is not supported.
【Motherboard Compatibility】: Supports standard ITX motherboards up to 170x170mm. When paired with an SFX power supply, it can also support non-standard mATX motherboards up to 225 x 208mm (8.86" x 8.19"). When paired with an ATX power supply, it can support non-standard mATX motherboards up to 225 x 186mm (8.86" x 7.32").
【GPU Compatibility】: The K77LITE features a 3.5-slot PCIe space, supporting GPUs up to 70mm (2.75") in height. With a full modular ATX power supply, the maximum supported GPU length is 230mm (9.0"). When using a non-modular ATX or SFX power supply, the GPU length can extend up to 280mm (11"). For GPUs longer than 230mm (9.0"), an SFX power supply is recommended. Additionally, the GPU's bracket height must be less than 33mm (1.3").
【Cooling Performance】: In air cooling mode, the K77LITE supports the installation of two 90mm fans at the top and one 90mm fan at the rear. In AIO water-cooling mode, only the two 90mm fans at the top are supported. Additionally, if space permits, up to three 90mm fans can be installed at the bottom. Despite its compact 11.6L volume, the K77LITE boasts excellent cooling performance.
【Storage Options】: The K77LITE can accommodate 1-6 2.5" SSDs (or HDDs). The number of SSDs that can be installed depends on the length of the GPU, the number of bottom-mounted fans, and the cables from the modular ATX power supply. Please refer to the diagram to determine the exact number of 2.5" SSDs that can be installed.
